ADC Conjugation Kit — Conjugation with Speed, Precision, and Reliability

Antibody-Drug Conjugates (ADCs) are targeted therapeutics structured as "Antibody-Linker-Payload". By precisely conjugating cytotoxic payloads (e.g., MMAE, DXd) to antibodies, ADCs enable targeted delivery of toxins to tumor cells. Conjugation technology critically influences ADC efficacy, safety, and manufacturability.

We have a new ADC Conjugation Kit, delivering a rapid, precise, and robust ADC preparation process. Generate functional ADCs within 3 hours while maintaining antibody activity and high recovery. The resulting conjugates are suitable for direct use in cellular or animal studies to accelerate candidate ADC screening.

Technology & Principle

Based on interchain cysteine conjugation technology, this kit reduces antibody disulfide bonds to generate reactive cysteine residues for non-site-specific maleimide conjugation. This classic strategy enables rapid, controlled ADC preparation—requiring only 3h to obtain ADC conjugates with homogeneous DAR. The resulting conjugates demonstrate significant cytotoxicity, offering a robust tool for ADC screening and mechanistic studies.

Product Features

Fast: Complete ADC prep in <3 hours

Precise: Controlled DAR 4/8 with preserved antibody activity

Efficient: >95% conjugation, >80% recovery

Low Input: Compatible with ≥2 mg/mL antibodies

Simple: 15 min purification via spin column

Protocol Overview

1. Prepare antibody solution for 2 mg/mL in 1×PBS buffer (pH7.2-7.4)

2. Antibody reduction 37°C, 1h

3. Antibody conjugation 23°C, 1h

4. Reaction quenching RT, 0.5h

5. Purification and buffer change

Product List

Components

The ADC Conjugation Kit (MMAE, DAR4, 200μg, for human IgG1) (Catalog No.: ADC-P013) as an example.

Cat.No.	Components ID	Components	Size (1 Kit)	Storage
Box A ADC-P013	C01	Reducing reagent	1 vial	-20℃
	C02	VcMMAE	1 vial	-20℃
	C03	Quencher reagent	1 vial	-20℃
Box B ADC-P013-1	Buffer01	1xPBS (pH7.2-7.4), 11%Trehalose	5 mL	4℃
Box B ADC-P013-1	Desalting column	Desalting Spin column, 0.5mL	1 per	4℃

Validation Data

The following ADC products were prepared using the ADC Conjugation Kit (MMAE, DAR4, 200μg, for human IgG1, Catalog No.: ADC-P013).

Antibody resource: Trastuzumab biosimilar

DAR and Purity Validation by HPLC (HIC + SEC)

Figure 1. The ADC was prepared using the ADC Conjugation Kit (MMAE, DAR4) and analyzed by HIC and SEC-HPLC. The average drug-antibody ratio (DAR) is 4.0±0.5, and the purity of the ADC is greater than 95%.

DAR Validation by Mass Spectrometry

Figure 2. The DAR (3.82) was calculated from the weighted average of the deconvoluted MS peak areas using LC-MS/MS. The results showed the deconvoluted mass spectra of light chains and heavy chains, and the increase in molecular weight caused by the conjugated payload (1316±3 Da). The heterogeneity in N-glycosylation of heavy chain adds to the complexity of the mass spectrum.

Validation of Antigen Binding Activity

Figure 3. Binding affinity of anti-Her2 antibody and anti-Her2 antibody–MMAE conjugate to human Her2 (Cat. No. HE2-H5225) as determined by BLI (Bio-Layer Interferometry). The conjugate exhibits nanomolar affinity (0.57 nM) for human Her2, comparable to the naked antibody (0.86 nM).

In Vitro Cytotoxicity Validation

Figure 4. In vitro cytotoxicity assays: The ADC can bind and internalize in target cells (SK-BR-3) with high expression of Her2 and release MMAE inside the cells to induce a cytotoxic effect (IC₅₀=0.0058 µg/mL). Meanwhile, no cytotoxicity was observed in Her2 receptor-negative cell lines (MDA-MB-231).

Performance Consistency Across Kit Sizes

Figure 5. In vitro cytotoxicity of products prepared by different size of the ADC Conjugation Kit (Cat. No. ADC-P013, ADC-P014). The result shows very high consistency (RSD＜10%).

Stability Validation

Figure 6. The MMAE-ADC was prepared using the ADC Conjugation Kit, which were left at 37℃ for 21 days. The ADCs were analyzed by HIC and SEC-HPLC. The average drug-antibody ratio (DAR) is 4.0±0.5, and the purity of the ADC is greater than 95%.

For technical support, please contact our dedicated product manager
